Compact 8 Channel Network Video Recorder with PoE (80Mbps) (4TB Hard Drive)

Brand logo
SKU NVR8COM3-4T
Brand logo

Compact 8 Channel Network Video Recorder with PoE (80Mbps) (4TB Hard Drive)

SKU NVR8COM3-4T

The NVR8COM3 is a compact network video recorder with Ultra HD broadcast-quality image performance and built-in 8 port power over Ethernet switch, allowing easy plug and play installation. It features the latest H.265+ compression technology and an industrial grade processor.

Product features:
• Records up to 4K Ultra HD resolution (3840 x 2160)
• 8CH NVR with 8 Power over Ethernet ports
• Up to 80Mbps total incoming bandwidth
• Decode up to 2 channels at 4K / 8 channels at 1080p (25fps)
• 1 x SATA port up to 10TB, max. 10TB HDD capacity
• Motion detection recording & record scheduling
• HDMI & VGA simultaneous video output
• Backup via external USB device or local network
• Remote view in seconds with setup via QR code

Links and Downloads

CE/ RCM Certificate
RoHS Certificate

Specifications

General
Main Processor
Industrial grade embedded processor
Operating System
Embedded Linux
Video Input
8 channels
PoE
Yes
HDD Capacity
Two-way Talk
1 channel input, 1 channel output, RCA
Interoperability
ONVIF (Profile S), CGI, SDK, RTSP
Display
Video Output
1 HDMI / 1 VGA
Display Resolution
Configurable from 3840 x 2160 to 1024 x 768
Display Split
1/4/8/9
OSD
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Recording Resolution
Configurable from 8.0MP (3840 x 2160) to CIF (352 x 288)
Incoming Bandwidth
80Mbps
Decoding Capacity
8 channels: 1080p (25fps)
Video Compression
H.265+ / H.265 / H.264+ / H.264
Bit Rate
N/A
Record Modes
Manual / Schedule (Regular [Continuous], Motion Detection, Alarm, Timed) / Stop
Record Interval
N/A
Features
Alarm Input / Output
N/A
Trigger Events
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Snapshot, Buzzer, Screentips, Log
Video Detection
General: Motion Detection, Smart Motion Detection, Video Loss, Privacy Masking, IPC Alarm / Anomlay: Device Offline, Storage Error, Network Security, IP/MAC Conflict
Playback Sync
1/4/8
Search Modes
Time/Date, Alarm, Motion Detection, Exact Search (to the second), Smart Search
Backup Modes
USB Device / Network
Network
Ethernet
1 RJ-45 port (10/100Mbps)
Power over Ethernet
8 ports (IEEE802.3at/af, 10/100Mbps)
Network Functions
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, P2P
Optical Interface
N/A
Max. User Access
128 users
Remote View
iOS (iPhone, iPad) / Android devices
Storage
Internal HDD
1 x SATA port up to 10TB, max. 10TB HDD capacity
HDD Modes
Single (no RAID compatibility)
USB Interface
2 ports: Rear USB2.0 / Front USB2.0
Auxiliary Inputs
N/A
Environment
Power Supply
48 ~ 53VDC / 1.8 ~ 2A
Power Consumption
NVR: <10W (without HDD) / PoE: Max 25.5W per port, 72W total
Operating Environment
-10 ~+55°C / 10~90%RH
Rackmountable
No
Rackmount Units
Compact 1RU
Dimensions
260mm x 225mm x 48mm
Weight
0.92kg (without HDD)
Warranty (Years)
4

Shipping Weight and Dimensions

Includes product packaging

Width
89 mm
Height
122 mm
Depth
76 mm
Weight
2.70 kg
