Complete 4 Channel Watchguard H.264 DVR with 1TB and Camera Kit 100FPS @ 704x576

Code DVR4ENTPACK5

Complete 4 Channel Watchguard H.264 DVR with 1TB and Camera Kit 100FPS @ 704x576

Code DVR4ENTPACK5

Utilising the latest H.264 video compression technology, the Watchguard DVR4ENTPACK5 complete surveillance package is ideal for a home or small business wanting to set up a digital surveillance system with network and remote access. It features H.264 Video Compression Technology - allowing for higher resolution image recording with smaller file sizes, Multiplex Operation allowing live display, record, playback and network operations simultaneously and Intelligent Video Motion Detection recording.

This complete surveillance package contains everything needed to set up the system with a 4 Channel Digital Video Recorder with 1TB hard drive, 4x10M IR Day/Night weatherproof cameras (Rated IP67), power supplies, camera connection cables (2 x 10m, 1 x 20m, 1x 30m) and 4x CCTV warning stickers . The system has been designed to allow quick and easy installation and comes with an easy to follow operation manual.

The DVR can record at each camera at D1 resolution (704 x 576) in real-time (25 fps). You can adjust the recorder settings for both image quality and frame rate, and when the HDD is full, you can set the DVR to automatically record over the oldest footage. If connected to a windows PC network, footage can be viewed over the network using the included software. If the network has a high-speed Internet connection, footage can also be viewed remotely over the Internet. The software also enables footage to be backed up / archived from the DVR to a PC allowing storage on another HDD or burning to a DVD or CD.

The included 1TB hard disk drive can record for approximately 16 weeks with all cameras set at D1 resolution at a recording rate of 6 frames per second, per camera. This should be ideal for most installations.

PACKAGE INCLUDES:
- 1 x 4 Channel H.264 DVR with 1TB Hard Drive
- 4 x Day / Night camera (10m IR range)
- 4 x Camera Connection Cables
- 2 x Switch Mode Low Voltage Power Supplies
- 4 x Highly Visible UV Resistant Window Warning Stickers
- 1 x Monitor Connection Cable
- 1 x Network Cable (Optional Use)
- 1 x Power Split Cable

Links and Downloads

Specifications

Alarm Input/Output
4 inputs, 1 output
Audio Input/Output
4 Channels/1 Channel
Backup Methods
USB 2.0 flash drive / Network
Hard Drive Bays
1, max. capacity 1TB
Max Record Framerate
100FPS
Max. Display Frame Rate
100FPS
Mobile Surveillance
Yes: iPhone, BlackBerry, Windows Mobile & Java
Power
DC 19V
PTZ Control
Yes
Recording Mode
Manual / Timer / Motion / Alarm / Remote
Recording Resolution
704 x 576 , 352 x 288
USB Mouse Control
Yes
Video Compression
H.264
Video Input
4 Channels
Video Outpus
VGA, Composite
Web Interface
Supports licensed software “Video Viewer” / Internet Explorer (10 users access simultaneously)
Warranty (Years)
TBA

Shipping Weight and Dimensions

Includes product packaging

Width
410 mm
Height
620 mm
Depth
150 mm
Weight
7.50 kg
