Complete 16 Channel Watchguard H.264 DVR with 2TB and Camera Kit

Code DVR16ENTPACK

Complete 16 Channel Watchguard H.264 DVR with 2TB and Camera Kit

Code DVR16ENTPACK

Utilising the latest H.264 video compression technology, the Watchguard DVR16ENTPACK complete surveillance package is ideal for a home or small business wanting to set up a digital surveillance system with network and remote access.
It features H.264 Video Compression Technology - allowing for higher resolution image recording with smaller file sizes, Multiplex Operation allowing live display, record, playback and network operations simultaneously and Intelligent Video Motion Detection recording.

This complete surveillance package contains everything needed to set up the system with a 8 Channel Digital Video Recorder with 2 TB hard drive, 12x10M IR Day/Night weatherproof cameras (Rated IP67), 4x indoor dome cameras, power supplies, camera connection cables (8 x 10m, 4 x 20m, 4x 30m) and 4x CCTV warning stickers . The system has been designed to allow quick and easy installation and comes with an easy to follow operation manual.

The DVR can can record up to 400 image frames per second (real time) at CIF resolution (ie. 25FPS per camera @ 352 x 288 pixels), and when the HDD is full, you can set the DVR to automatically record over the oldest footage. If connected to a windows PC network, footage can be viewed over the network using the included software. If the network has a high-speed Internet connection, footage can also be viewed remotely over the Internet. The software also enables footage to be backed up / archived from the DVR to a PC allowing storage on another HDD or burning to a DVD or CD.


PACKAGE INCLUDED:
- 1 x 16 Channel H.264 DVR with 2TB Hard Drive
- 12 x Day / Night camera (10m IR range)
- 4 x Indoor Dome Camera
- 16 x Camera Connection Cables
- 2 x Switch Mode Low Voltage Power Supplies
- 4 x Highly Visible UV Resistant Window Warning Stickers
- 1 x Monitor Connection Cable
- 1 x Network Cable (Optional Use)
- 4 x Power Split Cable
- 1 x Mouse

Links and Downloads

Specifications

Alarm Input/Output
16 inputs, 1 output
Audio Input/Output
4 Audio inputs, 2 Audio output (Mono)
Backup Methods
USB, Network
Dimensions(mm)
432(W) × 90(H) × 326(D)
Hard Drive Bays
Accommodates 2 SATA HDDs (1 HDD capacity up to 2TB)
Max Display Framerate
400FPS
Mobile Surveillance
Yes: iPhone, BlackBerry, Windows Mobile & Java
Power
19VDC
PTZ Control
Yes
Recording Rate
704 x 576(100fps), 704 x 288 (200fps), 352 x 288(400fps)
Resolution
704 x 576 , 352 x 288
USB Mouse Control
Yes
Video Compression
H.264
Video Input
16 Channels
Video Loop Outputs
16 Channels
Video Output
VGA, Composite
Warranty (Years)
TBA

Shipping Weight and Dimensions

Includes product packaging

Width
0 mm
Height
0 mm
Depth
0 mm
Weight
6.60 kg
