Professional Series Compact 13.56MHz Card Reader

Brand logo
SKU ACRDR-2PC2
Brand logo

Professional Series Compact 13.56MHz Card Reader

SKU ACRDR-2PC2

The ACRDR-2PC is a professional access control reader, capable of granting access via RFID card.

Product features:
• Compatible with 13.56MHz access control systems
• Gain access via RFID card
• Use with Door Access Control series for multiple units
• Connect and configure with PC via ethernet cable
• RS485 protocol
• Compact, textured design
• Tamper switch triggers loud alarm, deterring removal
• IP67 weather rated for outdoor use
• Blue backlight for low light visibility

Links and Downloads

CE/ RCM Certificate
RoHS Certificate

Specifications

Access
Product
RFID Reader
Communication
RS485 / Wiegand 26/34
RFID Format
13.56MHz
RFID Read Range
≤8cm
RFID Read Time
<0.1s
Fingerprint Scan
N/A
Keypad
N/A
Function
Audio
Buzzer
Light
Blue Backlight
Tamper Switch
Yes
Environment
Ingress Protection
IP67
Vandal Protection
N/A
Power Supply
5~15 VDC / 100mA
Operating Conditions
-30°~+60° C / Less than 95% RH
Dimensions
72 x 102 x 18mm
Net Weight
0.20kg
Other
Category
Access Control
Main Processor
8 Bit
Warranty (Years)
4

Shipping Weight and Dimensions

Includes product packaging

Width
80 mm
Height
130 mm
Depth
65 mm
Weight
0.25 kg
