Ubiquiti Unifi Dual Band Enterprise Access Point (PoE Excluded)

SKU WT5-UAPNANOHD-E

Stock may be limited. Please contact us for availability or for an alternative item.

The Ubiquiti Unifi Dual Band WiFi technology Enterprise Wave 2 Access Point provides a strong and expansive wireless coverage to all enterprise networking environments. With its elegant, nano-sized design, this access point can be staged virtually anywhere indoors where you'd like to enhance your wireless speed and performance.

At the front-center of the device is a status LED ring which can provide the administrator with location tracking and alerts for each device. Easily connect your devices to and manage the UniFi AP through the powerful mobile app.

Key Features:
• Simultaneous, dual-band operation
• 5 GHz (4x4 MU-MIMO) band @1733 Mbps
• 2.4 GHz (2x2 MIMO) band @300Mbps
• Powered via PoE (802.3af) (PoE Injector or PoE Switch sold separately)
• 200+ concurrent client capacity

Suggested Products

Suggested product image
UniFi PoE Device Adapter
POE-AF
Suggested product image
4-port Unmanaged Fast Hi-PoE Ethernet Switch
VSPOE-SWA4F

Links and Downloads

UniFi_nanoHD_AP_DS.pdf 6.35 MB
CE/ RCM Certificate
RoHS Certificate

Specifications

Antennas
Dual-Band Antenna, 2.4 GHz: 2.8 dBi, 5 GHz: 3 dBi
BSSID
Up to 8 per Radio
Dimensions
160 x 160 x 32.65 mm
Maximum Power Consumption
10.5W
Maximum TX Power(2.4 GHz)
23 dBm
Mounting
Wall/Ceiling (Kits Included)
Networking Interface
10/100/1000 Ethernet Port
Operating Humidity
5 to 95% Noncondensing
Operating Temperature
-10 to 70° C
Power Method
Power over Ethernet
Power Supply
UniFi Switch (PoE)
Weight
300 g (without mount)
Wi-Fi Standards
802.11 a/b/g/n/ac/ac-wave2
Wireless Security
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
Warranty (Years)
1

Shipping Weight and Dimensions

Includes product packaging

Width
205 mm
Height
90 mm
Depth
205 mm
Weight
1.00 kg
