VIP VISION 16 Channel Digital Output RS485 Module
Code
NVR-C28
Images
Related Categories
Overview
16 Channel external digital output module for a VIP VISION DVR or NVR. Product requires NVR-C08 for operation.
Links and Downloads
CE / RCM Certificate
|
| RoHS Certificate |
Additional Specifications
| Communication Interface | RS-485 differential 2 half / duplex wires |
| Communication Speed | Baud rate from 1.2 Kbps to 115.2 Kbps |
| Dimensions | 151 x 75 x 26 mm |
| Dual watchdog | Reset circuit module / Host operating status |
| Output Channel | 16 digital output channels |
| Power consumption | 1.5W |
| Power supply | Screw terminal, or external DC adapter |
| Signal LED | Power on, all output channels |
| Transmission distance | RS485 Up to 4000ft (1200M) |
Shipping Weight and Dimensions includes product packaging
| Width | 0 mm |
| Height | 0 mm |
| Depth | 0 mm |
| Weight | 0.00 kg |
